8
"A"
"B"
"C"
"D"
"E"
PRODUCT DIMENSIONS
ROUGH-IN OPENING DIMENSIONS CABINET DIMENSIONS
MODEL "A" "B" "C" "D" "E" "F" "G" "H" "J"
ML15WSG
15"
(38.1 cm)
**34" to 35"
(86.4 to 88.9 cm)
*
14 7 ⁄
8
"
(37.8 cm)
33 3 ⁄
4
" to 34 3 ⁄
4
"
(85.7 to 88.3 cm)
23 23 ⁄
32
"
(60.2 cm)
25 21 ⁄
32
"
(65.2 cm)
37 13 ⁄
32
"
(95 cm)
16 11 ⁄
16
"
(42.4 cm)
ML15WS(P) or (F)
15"
(38.1 cm)
**34 1 ⁄
4
" to 35 1 ⁄
4
"
(87 to 89.5 cm)
*
14 7 ⁄
8
"
(37.8 cm)
34" to 35"
(86.4 to 88.9 cm)
22 7 ⁄
8
"
(58.1 cm)
-
37 1 ⁄
2
"
(95.2 cm)
14 1 ⁄
8
"
35.9 cm)
ML24W*G
24"
(61 cm)
**34" to 35"
(86.4 to 88.9 cm)
*
23 7 ⁄
8
"
(60.7 cm)
33 3 ⁄
4
" to 34 3 ⁄
4
"
(85.7 to 88.3 cm)
23 23 ⁄
32
"
(60.2 cm)
25 21 ⁄
32
"
(65.2 cm)
46 13 ⁄
32
"
(117.9 cm)
25 11 ⁄
16
"
(65.2 cm)
ML24W*(P) or (F)
24"
(61 cm)
**34 1 ⁄
4
" to 35 1 ⁄
4
"
(87 to 89.5 cm)
*
23 7 ⁄
8
"
(60.7 cm)
34" to 35"
(86.4 to 88.9 cm)
22 7 ⁄
8
"
(58.1 cm)
-
46 1 ⁄
2
"
(118.1 cm)
23 1 ⁄
8
"
(58.7 cm)
DOOR STYLE
(G) Glass Frame Door
(P) Solid Overlay Door (no handle)
(F) Frame Glass Overlay Door (no handle)
If necessary to gain clearance inside
the rough-in opening a hole can be cut
through the adjacent cabinet and the
power cord routed through this hole to a
power outlet. Another way to increase the
available opening depth is to recess the
power outlet into the rear wall 1" (2.5 cm)
to gain the thickness of the power cord
plug.
Figure 7
Figure 7a
