Straight-through Cabling
Pin 1 Pin 1
Pin2 Pin 2
Pin3 Pin 3
Pin6 Pin6
Cross-over Cabling
Pin 1 Pin 3
Pin 2 Pin 6
Pin 3 Pin 1
Pin 6 Pin 2
Connect an Ethernet cable into any switch port and connect the other side to your attached device.
The green Link/Act LED will light up when the cable is correctly connected. Refer to the LED
Indicator section for descriptions of each LED indicator.
If a port LED is off, go back and check for connectivity problems between that port and the network
device it is connected to.
The maximum cable length for 10/100BaseT with Cat5 twisted pair cables is typically 100 meters
(328 ft.).
