A. C. MODULAR GENERATOR SYSTEM
Page 26 of 52
Figure 13
6. Return to system purge display by pressing the Mode switch repeatedly
until the screen shown in Figure 13 is displayed. Purge will still be active.
Indicates whether the
generator is
0n or 0ff
Example of display with purge option set
Figure 14
f. Engage the Power Take-Off (PTO). (Note: Pump may sound rough for a few
minutes due to entrapped air.) Make sure the Command & Control Center
displays the string “
0FF” as shown in Figure 14, press the On/Off switch to turn
the generator off, if needed.
g. Check for hydraulic fluid leaks, all hose connections must be tight. Monitor the
hydraulic fluid level, adding fluid as needed to keep the level in the sight
gauge full.
h. After 10 minutes, the system controller will automatically switch the generator to
“
0N”. Check to see that the generator is turning (The frequency display should
indicate
0n). If it is not, press the On/Off switch on the Command & Control
Center to start the generator.
i. After the generator has been operated for 20 minutes with the generator on, the
system controller will automatically disable the purge option.
