6.24
Thread Stand
Components
69 Ultra High Speed Overedge and Safety Stitch Machine | Instruction Manual and Parts List
3 thread 4 thread 5 thread
1 30102032 Thread bar (lower) 1 1 1
2 30128024 Washer 2 2 2
3 N02001 Nut 1 1 1
4 30101028 Bracket (3 spools) 1 0 1
5 30101029 Bracket (2 spools) 0 2 1
6 30102033 Spool pin 3 4 5
7 W02002 Washer 3 4 5
8 30101030 Thread guide bar (3 spools) 1 0 1
9 30111007 Spool tray 3 4 5
10 30123014 Cushion 3 4 5
11 30103044 Spool holder 3 4 5
12 L02004 Screw 1 2 2
13 10128006 Rubber washer 1 1 1
14 20131014 Thread stand support 1 0 1
15 30102034 Thread bar (upper) 1 1 1
16 30129005 Joint 1 1 1
17 S04002 Screw 4 4 4
18 N01004 Nut 6 6 6
19 30111008 Bracket 1 1 1
20 30113018 Thread guide bar 1 1 1
21 S04003 Screw 1 1 1
22 30101031 Thread guide bar (2 spools) 0 2 1
23 30111009 Bracket 1 1 1
24 S04004 Screw 3 3 3
25 N01005 Nut 7 8 9
26 30113019 Thread guide bar (5 holes) 1 1 1
28 30103045 Thread guide hole 3 4 5
29 30122027 Rod cap 1 1 1
30 20131023 Screw 1 1 1
31 20131024 Screw 1 1 1
32 30122027 Nut 1 1 1
No. Part No. Description
Qty
