6.12

Upper Looper

Components

45

Ultra High Speed Overedge and Safety Stitch Machine

|

Instruction Manual and Parts List

3 thread

4 thread

5 thread

1

20705002

Connection assembly

1

1

1

2

207S11016

Screw

2

2

2

3

207S11005

Screw

2

2

2

4

20704003

Crank assembly

1

0

0

5

20704004

Crank assembly

0

1

1

6

S05018

Screw

1

1

1

7

20702004

Shaft

1

1

1

8

20628006

Washer

1

1

1

9

207S11004

Screw

1

1

1

10

20628005

Spring washer

1

1

1

11

20708006

Spacer

0

1

0

12

20622019

Oil Seal

1

1

1

13

20708007

Spacer

1

0

1

14

20705003

Lever assembly

1

1

1

15

207S12002

Screw

1

1

1

16

20726004

Pin assembly

1

1

1

17

20523005

Oil wick

1

1

1

18

207S14010

Screw

1

1

1

19

20704005

Upper looper holder assembly

1

1

1

20

20623005

Felt

1

1

1

21

207S11025

Screw

1

1

1

22

XXXXXXXX

Upper looper

1

1

1

25

207S11026

Screw

2

2

2

26

20715007

Cover

1

1

1

27

207S17004

Screw

1

1

1

28

207S11027

Screw

1

1

1

29

20123021

Oil wick

1

1

1

30

20723005

Felt

1

1

1

31

20712017

Bracket

1

1

1

32

207S11020

Screw

1

1

1

No.

Part No.

Description

Qty
