Differencial feed components – SINGER 321D-241M-24 INDUSTRIAL SERGER User Manual

Page 55

background image

6.16

Differencial

Feed

Components

53

Ultra High Speed Overedge and Safety Stitch Machine

|

Instruction Manual and Parts List

3 thread

4 thread

5 thread

1

20705004

Connection

1

1

1

2

20626003

Pin

1

1

1

3

207S14007

Screw

1

1

1

4

BO8001

Needle bearing

1

1

1

5

20710001

Eccentric

1

1

1

6

20710002

Guide (Feed eccentric)

1

1

1

7

20712018

Flat spring

1

1

1

8

207S14003

Screw

2

2

2

9

20710003

Regulator assembly

1

1

1

10

207S14006

Screw

2

2

2

11

20710004

Eccentriv assembly

1

1

1

12

20727003

Spring

1

1

1

13

207S20005

Screw

1

1

1

14

20709006

Ratchet

1

1

1

15

20702005

Push button shaft

1

1

1

16

20722005

Gaket

1

1

1

17

001027

O ring

1

1

1

18

20728001

Washer

1

1

1

19

20727004

Spring

1

1

1

20

H05018

Ring

1

1

1

21

20705005

Link

1

1

1

22

207S20006

Screw

1

1

1

23

20629002

Ring

1

1

1

24

20704008

Lever assembly

1

1

1

25

S05018

Screw

1

1

1

26

20712019

Lever

1

1

1

27

207S20007

Screw

1

1

1

28

20702006

Shaft

1

1

1

29

20622010

O ring

1

1

1

30

20627006

Spring

1

1

1

31

20712020

Regulator plate

1

1

1

32

207S11008

Screw

2

2

2

33

20711007

Spacer

2

2

2

34

2071600100

Nut

1

1

1

35

207S300011

Screw

1

1

1

36

20728003

Spring washer

1

1

1

37

207S16002

Stopper

2

2

2

38

207S11011

Screw

2

2

2

39

30228009

Washer

2

2

2

40

20702007

Adjusting shaft

1

1

1

41

20737001

Label

1

1

1

42

H05018

Ring

1

1

1

43

20727005

Spring

1

1

1

44

20709007

Pin

1

1

1

No.

Part No.

Description

Qty
