6.14
Chain
Stitch Looper
Components (1)
49 Ultra High Speed Overedge and Safety Stitch Machine | Instruction Manual and Parts List
3 thread 4 thread 5 thread
1 20705006 Connection 0 0 1
2 B08002 Needle bearing 0 0 1
3 20704014 Crank 0 0 1
4 20703013 Bushing 0 0 1
5 207S12003 Screw 0 0 1
6 30228008 Washer 0 0 1
7 20709017 Slider 0 0 1
8 207S13009 Screw 0 0 1
9 20628010 Washer 0 0 1
10 20628005 Spring washer 0 0 1
11 20710008 Pin 0 0 1
12 001027 O ring 0 0 1
13 20626017 Shaft 0 0 1
14 20701034 Holder assembly 0 0 1
15 S05018 Screw 0 0 1
16 20704015 Crank assembly 0 0 1
17 S05018 Screw 0 0 1
18 20705008 Link 0 0 1
19 20703013 Bushing 0 0 1
20 207S12003 Screw 0 0 1
21 30228008 Washer 0 0 1
22 20702018 Shaft 0 0 1
23 3052201700 Oil seal 0 0 1
24 XXXXXXXX Chain stitch looper 1 1 1
25 207Sl1028 Screw 0 0 1
26 20701035 Chain stitch looper holder assembly 0 0 1
27 207S20004 Screw 0 0 1
28 20728002 Spacer 0 0 1
29 207S15001 Screw 0 0 1
No. Part No. Description
Qty
