6.15
Chain
Stitch Looper
Components (2)
51 Ultra High Speed Overedge and Safety Stitch Machine | Instruction Manual and Parts List
3 thread 4 thread 5 thread
1 20713039 Thread guide 0 0 1
2 207S11007 Screw 0 0 1
3 20713040 Thread guide 0 0 1
4 20629003 Holder 0 0 3
5 20612057 Bracket 0 0 1
6 207S20002 Screw 0 0 1
7 20628022 Washer 0 0 1
8 206S30015 Screw 0 0 1
9 20612055 Tension disc 0 0 2
10 3012016 Spring 0 0 1
11 206S16004 Knob 0 0 1
12 20612056 Thread guide 0 0 1
13 S01031 Screw 0 0 1
14 20629004 Thread guide 0 0 1
15 207S11020 Screw 0 0 1
16 20613017 Thread guide 0 0 1
17 207S11020 Screw 0 0 1
18 20612058 Looper thread take-up assembly 0 0 1
19 207S14009 Screw 0 0 2
20 20629005 Spring 0 0 1
21 20713026 Thread guide 0 0 1
22 207S11007 Screw 0 0 1
No. Part No. Description
Qty
