Overview • 31
English
4. OVERVIEW
4.1 Controls
seca 745/725 :
1
3
7
8
9
10 11
6
4
2
5
No. Control Function
1 Large sliding weight
Can be moved to set the weight display roughly
• Pull forward: release sliding weight
• Release: lock sliding weight in position
2 Small sliding weight
Can be moved to set the weight display
accurately
3
Tare weight with
knurled screw
Can be moved to balance the beam
• On initial use and before every weighing
operation
• To tare off an additional weight
4 Fine-tare screw
Can be adjusted to balance the beam exactly
• On initial use and before every weighing
operation
• To tare off an additional weight
5 Tray Where the baby is placed
6 Locking lever
• 2 pcs
• For locking the tray in position on the scale
housing
7
Pointer and counter-
pointer
Indicate whether the beam is balanced
8 Beam with scale For reading off the weight
9 Locking lever
For locking/releasing the beam
• Push down: lock in position
• Raise: release
