Model Front Rear Right Left Element
Any Voltage Cover Assembly Cover Assembly Side Panel Side Panel Support Bracket
CVEP-C-16/18/36 207-304644-101 207-304644-001 207-304644-201 304-304644-301 027-304646-001
CVEP-C-32/76 207-304644-102 207-304644-002 207-304644-201 304-304644-301 027-304646-001
CVEP-C-40/45/90 207-304644-103 207-304644-003 207-304644-201 304-304644-301 027-304646-001
Control Combination
Code Contactor Transformer
Coil Secondary
00 None None
30 24 Volt 24 Volt
31 24 Volt None
32 120 Volt 120 Volt
33 120 Volt None
34 208/240 Volt None
35 277 Volt None
Primary Secondary
Transformer
Voltage Voltage
208/240/480 24 315-304252-002
208/240/480 120 315-304252-001
277 24 315-304252-004
575 24 315-304252-005
277/575 120 315-304252-003
Code Thermostat
00 None
40 300-049197-003
42 300-113075-003
Contactor
Coil Voltage 30 Amp 50 Amp
24V 072-304551-001 072-304551-002
120V 072-304551-007 072-304551-008
208/240V 072-304551-013 072-304551-014
277V 072-304551-019 072-304551-020
7
REPLACEMENT PARTS
C V E P C kW Volts Phase Control Stat
* Included when unit is equipped with control(s).
