RENEWAL PARTS IDENTIFICATION
MANUFACTURER MODEL NUMBER BREAKDOWN (located on unit nameplate)
CVEP-C 36 2 1 30 42
5
Model
CVEP Explosion Proof Convection Heater
Temperature Rating
CVEP-C Code kW ID Number ˚F ˚C (BTU)
16 1.6 T3A 356 180 5,500
18 1.8 T2A 536 280 6,150
32 3.2 T3A 356 180 11,000
36 3.6 T2A 536 280 12,300
40 4.0 T3A 356 180 13,600
45 4.5 T2A 536 280 15,350
76 7.6 T2A 536 280 25,930
90 9.0 T2A 536 280 30,700
Code Voltage Maximum kW Allowable
1 120 1.8
2 240 9.0
3 380 9.0
4 480 9.0
5 415 9.0
6 575 9.0
7 277 9.0
8 208 9.0
9 600 9.0
Code Phase
1 1Ш
3 3Ш (Not available in 120, 277V)
Control Combination
Code Contactor Transformer
Coil Secondary
00 None None
30 24 Volt 24 Volt
31 24 Volt None
32 120 Volt 120 Volt
33 120 Volt None
34 208/240 Volt None
35 277 Volt None
Code Temperature Control
00 None
40 Thermostat 40 - 90˚F
Group B, C & D
42 Thermostat Group C & D
50 - 90˚F
