Page 1
Congratulations on your purchase of the Reliance Controls generator power transfer switch. Reliance has been
manufacturing transfer switches and equipment in Racine, Wisconsin since 1983 and has been producing high-quality
electrical equipment for nearly 100 years. Reliance is the Loadside® transfer switch used in nearly 90% of the installations
done by professional electricians. Your transfer switch is UL 1008 listed, C-UL listed, and meets all requirements of the
National Electrical Code.
7KLVtransfer switch LV made to operate with any generator having20 or 30 Amp twist-lock power receptacles.
TOOLS NEEDED FOR INSTALLATION
1. Power Drill
2. Wire Stripper and Cutter (10 to 14 gauge)
3. Insulated Screwdrivers
(#2 Phillips, 1/4" Flat Tip or #2 Square Tip depending on
your load center)
4. Hammer
5. Marking Pencil
6. Tape Measure
7. Seven Wall Anchors with at Least a 3/8” Flange
8. Enough 10-3 with Ground Building Wire to reach from
where you install your Outdoor Power Inlet Box to where
you install your transfer switch
9. Battery Powered Lighting during Installation
10. A Non-Contact Voltage Detector (optional)
PARTS LIST for 31406CRK POWER TRANSFER KIT
30 Amp 6-Circuit Transfer switch
30 Amp Outdoor Power Inlet Box
30 Amp 10-foot long Generator Power Cord
20 Amp Interchangeable Power Cord Plug
4 red and 6 yellow wire connectors
Installation and Operating Instructions
'9'
SAFETY SYMBOLS USED IN THIS MANUAL
Danger indicates an imminently hazardous
situation that, if not avoided, could result in
death or serious injury.
Warning indicates a potentially hazardous
situation that, if not avoided, could result in
death or serious injury.
Caution indicates a potentially hazardous
situation that, if not avoided, may result in
minor or moderate injury.
Reliance transfer switches covered
in this manual should not be used for
electric water heaters, clothes dryers, electric ranges,
central air conditioners or other appliances or systems
that may exceed the capacity of the product.
Improper installation of the transfer
switch could cause damage or
personal injury by electrocution or fire. Installation must be
performed by a qualified electrician, or others
knowledgeable of electrical systems, in compliance with
all applicable electrical codes.
DANGER
WARNING
CAUTION
WARNING
WARNING
Member of the National Electrical Manufacturers Association
Transfer switches are required for use with portable generators by Article
702 of the National Electrical Code
NOTE: The 30 Amp power cord plugs into this type of
generator power outlet:
If your generator only has a 20 Amp power outlet like this:
install the 20 Amp Power Cord Plug on your power cord
according to its included instructions.
3006 HDK
Reliance Controls Corporation is not responsible for
damage or injury caused by incorrect installation of
this transfer switch.
When the transfer switch is
connected to branch circuits with AFCI or GFCI breakers,
the AFCI or GFCI protection will be lost when, and only
when, the toggle switch is in the GEN position. To get
AFCI or GFCI protection when running on generator
power, it must be provided at the outlet(s).
The double pole branch circuits
connected to this transfer switch are considered live unless
both switches controlling the circuit are in the off position. The
position of the transfer switch circuit breakers are not to be
relied upon to disconnect the circuit.
WARNING
WARNING
