installation manual
3. ATTACHED FITTINGS
Please check whether the following fittings are of full scope. If there are some spare fittings , please restore them carefully.
QUANTITY
Tubing & Fittings
Remote controller & Its Frame
Drainpipe Fittings
Installation Fittings
SHAPE NAME
13. Expansible hook
3. Out-let pipe sheath
4. Out-let pipe clasp
5. Drain joint(on some models)
6. Seal ring(on some models)
11. Owner's manual
12. Installation manual
7. Remote controller
8. Remote controller holder
9. Mounting screw(ST2.9×10-C-H)
10. Alkaline dry batteries (AM4)
14. Installation hook
1. Installation paper board
(on some models)
(on some models)
(on some models)
(on some models)
4
1
4
1
1
1
1
1
1
1
2
2
1
1
2. Soundproof / insulation sheath
15 .Orifice
16 .Transfer connector( 12.7- 16)
(Packed with the indoor unit )
(NOTE: Pipe size differ from appliance
to appliance.To meet different pipe size
requirement, sometimes the pipe
connections need the transfer connector
to install on the outdoor unit .)
18 .Transfer connector( 9.52- 12.7)
(Packed with the indoor unit ，used for
multi-type models only)
(NOTE: Pipe size differ from appliance
to appliance.To meet different pipe size
requirement, sometimes the pipe
connections need the transfer connector
to install on the outdoor unit .)
1
1
(on some models)
1
(on some models)
17 .Transfer connector( 6- 9.52)
(Packed with the indoor unit )
(NOTE: Pipe size differ from appliance
to appliance.To meet different pipe size
requirement, sometimes the pipe
connections need the transfer connector
to install on the outdoor unit .)
1
(on some models)
