installation manual
Liquid side
Gas side
9. CONNECTIVE DIAGRAM
Orifice
Fig. 9-1
For ensuring throttled efficiency , Please mount the Orifice
assembly as horizontally as possible; and anti-shock rubber
should be wrapped at external of the Orifice for denoise.
NOTE
Fig. 9-2
CAUTION
Please purchase the fittings according to the requirements in
the manual strictly.
Refer the diagram when installing.
Mark the data plate with the Orifice installed(for some
models).
Liquid side
Liquid side
Indoor
Indoor
Outdoor
Outdoor
X
Liquid side
Indoor
Outdoor
X
1. Cooling&heating
Fig. 9-3
Liquid side
Liquid side
Indoor
Indoor
Outdoor
Outdoor
Liquid side
Indoor
Outdoor
X
2. Cooling only
