408
Practical hints
Replacing bulbs
Low beam bulb (halogen headlamps
only)
̈ Turn housing cover 1 counterclock-
wise and remove it.
̈ Turn bulb holder 6 with the bulb coun-
terclockwise and remove it.
̈ Pull the bulb at its socket out of bulb
holder
6.
̈ Insert the new bulb so that its socket
locates in the recess of bulb holder
6
and is level to it.
̈ Reinsert bulb holder 6 with the bulb in
the lamp and turn clockwise.
̈ Align housing cover 1 and turn it
clockwise.
High beam bulb/high beam flasher
bulb (halogen headlamps)/high beam
flasher bulb (Bi-Xenon* headlamps)
̈ Turn housing cover 2 counterclock-
wise and remove it.
̈ Turn bulb holder 4 with the bulb coun-
terclockwise and remove it.
̈ Pull the bulb at its socket out of bulb
holder
4.
̈ Insert the new bulb so that its socket
locates in the recess of bulb holder
4
and is level to it.
̈ Reinsert bulb holder 4 with the bulb in
the lamp and turn clockwise.
̈ Align housing cover 2 and turn it
clockwise.
Front turn signal lamp bulb
̈ Turn bulb socket 3 with the bulb
counterclockwise and remove it.
̈ Press gently onto the bulb and turn
counterclockwise out of bulb
socket
3.
̈ Press the new bulb gently into bulb
socket
3 and turn clockwise until it
engages.
̈ Place bulb socket 3 back into the
lamp and turn it clockwise.
