Page 268
X
To open: open cover : (
X
To remove the insert: reach into the
recess on the rear of insert =.
X
Lift insert = up ; and out.
X
To re-install the insert: press insert =
into the opening from above and press it
down until it engages.
Ashtray in the second row of seats
Short wheelbase vehicles with a center
console in the second row of seats do not
have an ashtray below the center console.
:
Cover
;
Insert
X
To open: open cover : (
X
Fold cover : down in the direction of the
arrow as far as it will go.
X
To remove the insert: press insert : in
the direction of the arrow.
X
Pull insert : upwards and remove it.
X
To re-install the insert: replace insert :
into the opening from above.
X
Push insert : down until it engages.
X
To close: pull cover ; upwards until it
engages in the first position.
X
Swing cover ; forwards until it engages in
the second position.
Cigarette lighter
G
WARNING
When leaving the vehicle, always remove the
SmartKey from the ignition lock. Always take
the SmartKey with you and lock the vehicle.
Do not leave children unattended in the
vehicle, even if they are secured in a child
restraint system, or with access to an
unlocked vehicle. A child's unsupervised
access to a vehicle could result in an accident
and/or serious personal injury. The children
could:
R
injure themselves on parts of the vehicle
R
be seriously or fatally injured through
excessive exposure to extreme heat or cold
R
injure themselves or cause an accident with
vehicle equipment that can be operated
even if the SmartKey is removed from the
ignition lock or removed from the vehicle,
such as seat adjustment, steering wheel
adjustment, or the memory function
266
Features
Stowing and features
