X Insert bulb holder :.
X Replace the cover in the front wheel arch
(
Y page 121).
Side marker lamp
X Remove the cover in the front wheel arch
(
Y page 121).
X Turn housing cover : counter-clockwise
and pull it out.
X Pull out bulb holder ;.
X Take the bulb out of bulb holder ;.
X Insert the new bulb into bulb holder ;.
X Insert bulb holder ;.
X Align housing cover : and turn it
clockwise.
X Install the cover in the front wheel arch
(
Y page 121).
Changing the rear bulbs
Opening and closing the side trim
panels
You must open the side trim panel in the
cargo compartment before you can change
the bulbs in the backup lamp.
Left-hand side trim panel
Right-hand side trim panel
X To open: insert a suitable object, e.g. a
coin, into the slot of release knob : on
side trim panel ;.
X Turn release knob : 90° in the direction
of the arrow and remove side trim
panel ;.
X To close: insert side trim panel ; and turn
release knob : 90° in the opposite
direction to the arrow.
Backup lamp
X Switch off the lights.
X Open the cargo compartment.
X Open the side trim panel ( Y page 123).
Replacing bulbs
123
Lights and windshield wipers
