61 LOSI LST XXL 2 • INSTRUCTION MANUAL
Part # English Deutsch Français Italiano
LOSA6247 2-56 x 3/4” Cap Head Screw 2-56 x 3/4 Inbusschraube Vis CHC 2-56 x 3/4 2-56 x 3/4” Vite testa a brugola
LOSA6250 4 & 5mm Setscrews (4 ea) 4 u. 5mm Madenschrauben (je 4) Vis HC M4 et M5 (4 de chaque) 4 & 5mm Grani (4 ea)
LOSA6307 5-40 Nuts - Lock & Hex (4 ea) 5-40 Stopmutter Ecrous freins 5-40 (4)
5-40 Dadi auto bloccanti ed esagoni
(4 ea)
LOSA6305 4-40 Steel Locknuts 4-40 1/2 Muttern Stahl (10) Ecrous frein inox 4-40 4-40 Autobloccanti in acciaio
LOSA6321 5mm Locknuts - R & L Thread (4 ea)
5mm Stopmutter/Rechts Links drehend
(je 4) Ecrous freins M5 -Pas à gauche et à
droite (4 de chaque) 5mm Dadi autobloccanti con fi letto
destro e sinistro (4 ea)
LOSA6350 #4 x 1/8” Hardened Washers Unterlegscheiben #4 and 1/8 gehärtet Rondelles trempées #4x 1/8 #4 x 1/8” Rondelle indurite
LOSA6355 2.2 & 3.6mm Washers (6 ea) 3.6 x 10mm U-Scheiben (6) Rondelles 2.2 et 3.6mm (6) 2.2 & 3.6mm rondelle (6 ea)
LOSA6356 5 & 6mm Shim Set Unterlegescheiben 5mm / 6mm Set de cales de 5 et 6mm 5 & 6mm Shim Set
LOSA6937 5 x 10mm Shielded Ball Bearings (2) 5x10mm Kugellager gekapselt(2) Roulement fl asqué 5x10mm (2)
5 x 10mm Cuscinetti a sfere schermati
(2)
LOSA6939 6 x 10mm Shielded Ball Bearings (4) 6x10mm Kugellager gekapselt (4) Roulement fl asqué 6x10mm (4)
6 x 10mm Cuscinetti a sfere schermati
(4)
LOSA6940 6 x 12mm Shielded Ball Bearings (4) 6x12mm Kugellager gekapselt (4) Roulement fl asqué 6x12mm (4)
6 x 12mm Cuscinetti a sfere schermati
(4)
LOSA6941 6 x 12mm Flanged Ball Bearings (4) 6x12 Kugellager m. Flansch (4) Roulement épaulé 6x12mm (4)
6 x 12mm Cuscinetti a sfere schermati
(4)
LOSA6942 8 x 16mm Sealed Ball Bearings (4) 8x16mm Kugellager (4) Roulement étanche 8x16mm (4) 8 x 16mm Sealed Ball Bearings (4)
LOSA6944 15x21x4mm Shielded Ball Bearings 15x 21x4mm Kugellager gekapselt(2) Roulement fl asqué 15x21x4mm
15x21x4mm Cuscinetti a sfere
schermati
LOSB3951 Differential Shims (13mm) (LST/2/AFT)
Diff Unterlegscheiben (13mm) LST/2/
AFT)
Cales de différentiel (13mm) Rasamenti diff. (13mm) (LST/2/AFT)
LOSB4001 93mm Turnbuckle Set w/Ends (2) (LST)
Gewindestiftsatz R/L/m.End, 93mm
(2): LST
Biellettes 93mm avec chapes (2)
93mm Set tenditori c/terminali (2)
(LST)
LOSB4020 Rod Eds & Pivot Balls (8) (LST) Kugelpfanne und Pivot Kugel (8) (LST) Chapes avec rotules (8) Attacchi a sfera (8) (LST)
LOSB4104 Pivot Pin Set (4 ea) (LST) Querlenkerstifte aussen (je 4) (LST2) Set d'axe des pivots (4) Set perni rotanti (4 ea) (LST)
LOSB4111 Spindle Bearing Spacer Set (LST/AFT)
Kugellagerdistanzhülse im Radträger
8LST/AFT) Set d'entretoises pour roulements de
fusées Set distanziali cuscinetti perni (LST/
AFT)
LOSB4201 Steering Hardware Set (LST/2) Schraubenset für Lenkung (LST/2) Accessoires de direction Set viteria sterzo (LST/2)
LOSB4203 Fwd/Rev & Brake Arms (LST/2/AFT)
Vorwärts/rückwärts Anlenkhebel
(LST/2/AFT)
Leviers de frein et de marche AV/ARR
Bracci avanti/indietro e freno (LST/2/
AFT)
LOSB4204
Throttle, Brake Reverse Linkage Set
(LST) Anlenkset Gas Bremse Rückwärtsgang
(LST2) Set de tringleries de gaz, de freins et
de marche arrière Set comandi motore, freno reverse
(LST)
LOSB4250 Servo Saver & Mount Set (LST/2)
Servo-Saver u. Befestigungssatz
(LST/2)
Set de sauve-servo et de fi xations Set salva servo e supporto (LST/2)
LOSB4603 4-Way Wrench (Steel). 4-fach Schraubenschlüssel (Stahl) Clé en croix en inox Chiave in acciaio a 4 vie (Steel)
TLR8202 Body Clips Body Clips Clips de carrosserie Clips carrozzeria
TLR237000 5 x 8mm Shielded Ball Bearings 5x8x2.5mm Kugellager (2) Roulement fl asqué 5x8mm 5 x 8mm Cuscinetti a sfere schermati
ENGINE PARTS • ENGINE PARTS • PIÈCES MOTEUR • PARTI MOTORE
DYNE0500 .31 Gas Engine .31 Benzin Motor Moteur essence .31 .31 Motore a benzina
DYNE0505 .31 Gas Engine with CDI
.31 Benzinmotor (5,5cc) m.
Einspritzung
Moteur essence .31 avec CDI .31 Motore a benzina con CDI
DYNE0510 Cylinder Head Screws (16): .31 .31:Zylinderkopfschrauben Moteur .31 - Vis de culasse (16) Viti testa cilindro (16): .31
DYNE0511 Cylinder Head Upper: .31 .31: Zylinderkopf oberes Teil
Moteur .31 - Partie supérieure de la
culasse
Testa cilindro superiore .31
DYNE0512 Cylinder Head Lower: .31 .31: Zylinderkopf unteres Teil
Moteur .31 - Partie inférieure de la
culasse
Testa cilindro inferiore .31
DYNE0513 Head Button: .31 .31: Zylinderkopfzentralstück Moteur .31 - Insert de culasse Viti testa .31
DYNE0514 Head Shims .1mm (2), ,2mm (2): .31 .31: Unterlegscheibe .1mm
Moteur .31 - Joint de culasse ep
0.1mm (2) et 0.2mm (2) Rasamenti testa.1mm (2), ,2mm (2):
.31
DYNE0516 Piston/Sleeve/Connecting Rod: .31 .31: Laufbuchse / Kolben/ Pleuel Moteur .31 - Piston/chemise/ bielle Pistone/Cilindro/Biella .31
DYNE0517 Connecting Rod: .31 .31: Pleuel Moteur .31 - Bielle Biella: .31
DYNE0518 Wrist Pin w/clips: .31 .31: Kolbenbolzen Moteur .31 - Axe de piston avec clips Spinotto c/clips .31
DYNE0519 Clutch Nut: .31 .31: Kupplungsmutter Moteur .31 - Ecrou d'embrayage Dado frizione: .31
DYNE0520 Flywheel 42mm: .31 .31: Schwungrad 42mm Moteur .31 - Volant diam. 42mm Volano 42mm: .31
DYNE0521 Collet: .31 .31: Stellring Moteur .31 - Cône Collare conico: .31
DYNE0522 Carb. Retain Post Set: .31 .31: Vergaserhaltestift
Moteur .31 - Set de fi xation de
carburateur
Set fermo carburatore: .31
DYNE0523 Exhaust Manifold Gasket: .31 .31: Krümmerdichtung Moteur .31 - Joint d'échappement Guarnizioni scarico: .31
DYNE0524 Front Bearing (7x19x6): .31 .31: Kugellager vorne (7x19x6) Moteur .31 - Roulement avant 7x19x6 Cuscinetto anteriore (7x19x6): .31
DYNE0525 Rear Bearing (14x25.5x6): .31 .31:Kugellager hinten (7x19x6)
Moteur .31 - Roulement arrière
14x25.5x6
Cuscinetto posteriore (14x25.5x6): .31
DYNE0526 Crankcase: .31 .31: Kurbelgehäuse Moteur .31 - Carter Carter: .31
DYNE0527 Crankshaft: .31 .31: Kurbelwelle Moteur .31 - Vilebrequin Carter: .31
