16
NOTE: The CG2100 server does not support all SAS or SATA drive models. For a list of
validated hard drive manufacturers and hard drive types, refer to the Tested
Hardware and Operating System List (THOL) on the Kontron website at
http://us.kontron.com/support/ (search for CG2100, click on Product Downloads,
then Compatibility Matrix).
Drives can consume up to 12W of power, each. Drives used in this server must be
specified to run at a maximum ambient temperature of 40°C.
2.7 SD Flash Module
There is an optional front-accessible USB SD flash module that supports two SD cards.
For a list of validated SD cards to use with this module, see the Tested Hardware and
Operating System List (THOL) on the Kontron website at
http://us.kontron.com/support/
(search for CG2100, click on Product Downloads, and then Compatibility Matrix).
2.8 Server Board (Baseboard)
The CG2100 server uses the Intel® server board T5520UR for the baseboard. The
processors and memory DIMMs are on the server board and support for several optional
accessories, such as a 280-pin Intel® adaptive riser card slot super slot, personality
modules, and GCM4, also .
Figure 7 shows the key component and connectors on the T5520UR server board.
Figure 7. Baseboard Components and Connectors
ITEM Description ITEM Description
