10
Feature Description
Capabilities Three full-height PCI Express* slots (passive)
Five-slot PCI-X riser:
Two full-height PCI-X slots with on-board PCI
Express to PCI-X bridge chips
One full-height PCI Express slot and two low-profile
PCI Express slots
Five-slot PCI Express riser:
Three full-height PCI Express slots and two low-
profile PCI Express slots
Hard Drive Options
Up to six 2.5-inch SAS or SATA hard drives
SAS/SATA RAID drive controller
SAS/SATA backplane
Peripherals
Up to two SD flash modules (front panel access)PCI
riser card assembly bracket
Front Panel
Buttons
Power on/off
System reset
Chassis ID
NMI
Front Panel LEDs
Power status
Chassis identification
System status
Fan status
HDD activity/fault
NIC activity
Alarms (critical, major, minor, power)
Power Supply Up to two 600W power supply modules (AC or DC)
Fans
Four redundant, hot-swappable CPU/memory area cooling
fans
Two redundant, hot-swappable PCI area cooling fans
Two optional redundant power supply fans (with PS
redundancy configuration only)
System Management
On-board ServerEngines* LLC Pilot II Controller
Integrated Baseboard Management Controller (Integrated
BMC), IPMI 2.0-compliant
Integrated Super I/O on LPC interface
2.1 Server Components
Figure 2 shows the CG2100 server with top covers and front bezel removed to show the
internal components.
