OM6062R Component Description
ID: 1031-6374, Rev. 1.0 Page 2 - 15
2.5 Mounting Brackets
For rack or wall mounting, there are special optionally available mounting brackets. These
brackets come in pairs either for top/bottom or side mounting. The top/bottom bracket pair is
symmetric and the left/right bracket pair is symmetric. They may be installed either at the front
of the subrack or at the rear as necessary. If brackets are required, the type must be specified
when ordering the OM6062R.
Figure 2-12: Top/Bottom Mounting Brackets (Front and Rear)
front
top
front
bottom rear
bottom
rear
top
