OM6062R Introduction
ID: 1031-6374, Rev. 1.0 Page 1 - 5
1.3 Technical Specification
Table 1-1: OM6062R Shelf Specifications
FEATURES SPECIFICATIONS
Shelf
Mechanical MicroTCA™ cube form designed for Single or Double Mid-size AMC Modules
• Dimensions: 215.00mm x 187.24mm x 221,45mm (depth x width x height)
(Without the feet being installed)
• Slot geometry (from left side of the subrack):
slot 1: occupied by pluggable Power Supply Unit (Double Full-size)
slot 2: reserved for MicroTCA™ Carrier Hub - MCH
(Single or Double Full-size Module)
slot 3: allocated for either Single or Double Mid-size AMC module
to
slot 8: allocated for either Single or Double Mid-size AMC module
• Fan bay located at bottom-front of the shelf
• Weight: 4,40 kg: shelf with PSU and fans
4,95 kg: typical configuration with PSU, AM4901 MCH, and AM5010
CPU board
5,10 kg: typical configuration with PSU, AM5901 MCH, and AM5010
CPU board
Backplane MicroTCA™ compliant, single-tier backplane with:
• six AMC module connectors
• one single tongue MCH connector
• one pluggable Power Supply Unit connector
• two connectors for interfacing to an optional onboard MCH module
• four fan connectors
Input power distribution and control functionality
PCIe clock generation and distribution
Fan speed control
Backplane FRU data EEPROM
Fabrics:
• twelve port, single-star Gigabit Ethernet Fabric (two ports to each AMC slot)
• four port PCIe, one lane each from AMC#1 slot to AMC slots 2, 3, 4 and 5
(no PCIe connection to AMC#6 slot)
• three pairs of SATA ports (AMC Ports 2 and 3):
• AMC#1 to AMC#2
• AMC#3 to AMC#4
• AMC#5 to AMC#6
IPMB-L and I²C interfacing supported for IPMI and local monitor and control
Optional mezzanine Compatibility Module available to support a third-party MCH
Temperature Ranges:
• Operating: -5°C to +55°C
• Storage: -40°C to +70°C
