12. Technical Data KISS 4U V2 EATX – User's Guide (Version 1.02)
12.1. Electrical Specifications
The corresponding electrical specifications of your KISS 4U V2 EATX platform can be found on the type label.
12.2. Mechanical Specifications
Dimensions KISS 4U V2 EATX
Height 4U (177 mm) (6.968 ”)
Width Front: 19” (482 mm); Chassis: 430 mm (16.9")
Depth Chassis: 472.5 mm (18.6“)
Weight (without Packaging) Approx. 18 kg (39.6 lbs.)
Chassis Chassis, black (RAL 7021)
Front access panel, blue (RAL 5017)
12.3. Environmental Specifications
Thermal Management 3x system fan (temperature-controlled fan slide-in module)
2x CPU fan
1x PSU fan
Operating Temperature 0 … +50 °C; (+55 °C at 10% POH per month)
(32 .. 122 °F; (131 °F at 10% POH per month)
Storage / Transport
Temperature -20 … +70 °C
(-4 … 158 °F)
Relative Humidity
(Operating/Storage/Transit)
10-95 % @ 40° C non condensing
Max. Operation Altitude 2,000 m (6,560 ft)
Max. Storage / Transport
Altitude
10,000 m (32,810 ft)
Operating Shock 15 G, 11 ms, half sine
Storage / Transit Shock 30 G., 11 ms, half sine
Operating Vibration 10 – 500 Hz, 1.0 G
Storage / Transit Vibration 10 – 500 Hz, 2.0 G
Acoustic Noise < 40 dB(A) at 1 m in front of the system
Protection Class Front: IP20; optional IP52
