7. Product Description
KISS 4U V2 EATX – User's Guide (Version 1.02)
Legend for Fig. 20 and Fig. 21:
1 AC power supply unit (PSU)
2 Power supply fan
3 AC input connector
4 “On/Off” switch of the power supply unit
5 Interfaces of the server board (depending on the
system configuration)
6 Free expansion card slots (depending on the
system configuration ordered)
7 Air exhaust openings
8 Rear side of the cover with captive knurled screws
9 Grounding stud (without PE sign)
10 Externally accessible screw (countersunk screw M3x6) for the
fastening of the card retaining bracket
11 Cut-outs for optional (customer-specific) interfaces routed to
the rear panel (9-pin D-SUB type)
7.3.1. Interfaces on the Rear Side
The positioning and number of the KISS 4U V2 EATX platform interfaces on the rear side may vary
depending on the system configuration.
Information and technical data can be found in the manual of the installed KTC5520/EATX or X9DR3F
Server Board. You can download the relevant motherboard manual for your system from our web site at
See also “KISS 4U V2 EATX Systems - Configuration
Guides” on our website.
7.3.1.1.
Interfaces routed to the Rear Panel
On-board interfaces can be routed to the rear panel (refer to Fig. 20 and Fig. 21, pos. 11).
A detailed description of the interfaces can be found in the manual of the installed server board
(KTC5520/EATX or X9DR3-F).
You can download the relevant manual for your system from our web site at
selecting the product. See also “KISS 4U V2 EATX Systems - Configuration Guides” on our website.
