12. Technical Data KISS 4U V2 EATX – User's Guide (Version 1.02)
12.
Technical Data
KISS 4U V2 EATX-xxxxxxxx-y KISS 4U V2 KTC 5520-y KISS 4U V2 X9DR3FB-y
Installed Board KTC 5520 X9DR3-F
Operating elements
(at the front side) 1x Power button
1x SYSID button 1x Power button
SYSID button (not available)
LED Indicators
(at the front side) 1x Power LED (green)
1x HDD LED (yellow)
1x LAN1 LED (green)
1x LAN2 LED (green)
1X SYSF1 LED (green)
1x SYSF2 LED (red)
1x SYSID LED (green) 1x Power LED (green)
1x HDD LED (yellow)
1x LAN1 LED (green)
1x LAN2 LED (green)
1X SYSF1 LED (red)
1x SYSF2 LED (red)
SYSID LED (not available)
At the front side:
2x USB (2.0)
Interfaces
At the rear side:
I/O intefaces of the installed server board
Drive Bays Up to four drive bays
* Optional equipment, depending on the system configuration ordered
(see also “KISS 4U V2 EATX Systems - Configuration Guides”)
Free expansion Slots Up to six slots
* Optional equipment, depending on the system configuration ordered
(see also “KISS 4U V2 EATX Systems - Configuration Guides”)
Lithium Battery (CMOS) * See manual of the installed sever board
DC Connection
(at the rear side) “+” and “-“ screw terminals
DC PSU LED Indicator
(at the rear side) “POWER-ON” LED of the installed PSU
AC Connection
(at the rear side) IEC C14 inlet connector with or without ON/OFF power switch (depending on the
installed PSU)
ON/OFF Switch of the AC/DC PSU
(at the rear side) depending on the equipped AC/DC PSU
AC or DC Rated Voltage Range See type label
KISS 4U V2 EATX = system type
The “ xxxxxxxx” group is replaced by up to a max. 8-digit combination of numbers, letter or space, and
represents the installed CPU board
The “ y” is replaced by a single letter (A through Z) representing the power supply installed into the
system.
The corresponding “KISS 4U V2 EATX Systems - Configuration Guides” and the manual of the installed CPU
board can be downloaded from our web site at
www.kontron.com by selecting the product name.
