7. Product Description

KISS 4U V2 EATX – User's Guide (Version 1.02)

7.3. Rear Side

On the rear side, depending on the ordered KISS 4U V2 EATX platform configuration, there are available the external
interfaces of the integrated server board, any additional interfaces, the power supply unit and the air exhaust openings.

Fig. 20: Rear side of the KISS 4U V2 EATX platform (shown with KTC 5520 motherboard and AC wide range PSU)

Fig. 21: Rear side of the KISS 4U V2 EATX platform (shown with X9DR3-F motherboard and AC wide range PSU)
