Product Description
20 KISS-Stor 1 – User’s Manual
Rebuilding Activity / Error Message Indicators
Rebuilding Activity
This row of eight indicators shows disks rebuilding activity. In normal operation, a
green light scans across the bank of indicators. If you are using the recovery
feature to rebuild a drive, all the indicators will turn on at the same time. The left-
side indicator blinks and then turns off when 12.5% of the data has been mirrored.
Then the next indicator blinks and turns off when 25% of the data has been
mirrored, and so on.
Error Messages
The chart offers the all-possible error messages, and can help you to identify
certain problems.
LED Error Status Display
Disk fail (replace the failed disk with another disk)
Target disk size is smaller than the source disk (replace the failed target
disk with a disk that its size is greater or equal to the source disk.)
Disk has bad sector (replace the failed disk with another disk)
Fan Fail (Contact Kontron Support Department)
No battery (Contact Kontron Support Department)
