Product Description
18 KISS-Stor 1 – User’s Manual
Legend for Fig. 4 and 4a:
1 2x drive carrier
2 Disk activity LED indicators
3 Drive carrier lock
4 Hard Disk Status / Rebuild
Indicators of the top installed HD
drive
5 Hard Disk Status / Rebuild
Indicators of the bottom installed
HD drive
6 Error messages LED Indicators
7 Drive carrier lock - Unlocked
orientation
8 Drive carrier lock – Locked
orientation
9 Green disk activity LED indicator
10 Amber disk activity LED indicator
11 Red disk activity LED indicator
Disk Activity LED-Indicators
The disk activity LED indicators show the status of each individual disk drive
(refer to fig. 4a ).
LED Indicator Disk Activity
Green Disk drive is properly installed and locked
Amber Disk drive is being accessed
Red Disk drive is not present, is not properly installed, is unlocked,
or disk has failed
Red Flashing Disk drive is rebuilding data
In the event that a drive fails, the red indicator turns on and an
alarm sounds. You can turn off the alarm by unlocking the drive
carrier.
