COMe-mCT10 / BIOS Operation
South Bridge
Feature Options Description
PCIe ExpressCard0 Port 0
Port 1
Port 2
Port 3
Disabled
Controls PCIe Port for ExpressCard support
PCIe ExpressCard1 Port 0
Port 1
Port 2
Port 3
Disabled
Controls PCIe Port for ExpressCard support
DMI Link ASPM Control Disabled
Enabled The control of Active State Power Management on both
NB side and SB side of the DMI Link
PCIe ExpressCard0 Disabled
Port 0
Port 1
Port 2
Port 3
Select a PCI Express High Priority Port
PCI-Exp. High Priority Port Disabled
Enabled Enable or Disable PCI Express Clock Gating for each root
port
High Precision Timer Disabled
Enabled Enable or Disable the High Precision Event Timer
SLP_S4 Assertion Width Disabled
1-2 Seconds
2-3 Seconds
3-4 Seconds
4-5 Seconds
Select a minimum assertion width of the SLP_S4# signal
Restore AC Power Loss Power Off
Power On
Last State
Select AC power state when power is re-applied after a
power failure
