COMe-mCT10 / Product Specification
3 Product Specification
3.1 Module definition
The COM Express® mini sized Computer-on-Module COMe-mCT10 (NUP1) follows pin-out Type 10 and is compatible to
PICMG specification COM.0 Rev 2.0. The COMe-mCT10, based on Intel's Cedar Trail platform, is available in different
variants to cover the demand of different performance, price and power:
Commercial grade modules (0°C to 60°C operating)
Part Number Product Name Processor DDR3 Flash UART TPM onboard FAN
34005-4032-19-7 COMe-mCT10 D2550 4/32GB Cedarview-D Intel® Atom™ D2550 4GB 32GB MLC 2 YES YES
34005-2040-19-6 COMe-mCT10 D2550 2GB/4GB Cedarview-D Intel® Atom™ D2550 2GB 4GB SLC - - YES
34005-1040-19-2 COMe-mCT10 N2800 1GB/4GB Cedarview-M Intel® Atom™ N2800 1GB 4GB SLC - - YES
34005-1040-16-2 COMe-mCT10 N2600 1GB/4GB Cedarview-M Intel® Atom™ N2600 1GB 4GB SLC - - -
34005-2040-16-2 COMe-mCT10 N2600 2GB/4GB Cedarview-M Intel® Atom™ N2600 2GB 4GB SLC 2 - -
34005-2000-19-6 COMe-mCT10 D2550 2GB Cedarview-D Intel® Atom™ D2550 2GB - 2 - YES
34005-2000-19-2 COMe-mCT10 N2800 2GB Cedarview-M Intel® Atom™ N2800 2GB - 2 - YES
34005-2000-16-2 COMe-mCT10 N2600 2GB Cedarview-M Intel® Atom™ N2600 2GB - 2 - -
34005-1000-19-6 COMe-mCT10 D2550 1GB Cedarview-D Intel® Atom™ D2550 1GB - - - YES
34005-1000-19-2 COMe-mCT10 N2800 1GB Cedarview-M Intel® Atom™ N2800 1GB - - - YES
34005-1000-16-2 COMe-mCT10 N2600 1GB Cedarview-M Intel® Atom™ N2600 1GB - - - -
Extended temperature grade modules (E1, -25°C to 75°C operating)
Part Number Product Name Processor DDR3 Flash UART TPM onboard FAN
34005-2040-19-6EXT COMe-mCT10 D2550 2/4GB E1 Cedarview-D Intel® Atom™ D2550 2GB 4GB SLC - - YES
34005-1000-19-2EXT COMe-mCT10 N2800 1GB E1 Cedarview-M Intel® Atom™ N2800 1GB - - - YES
34005-2000-16-2EXT COMe-mCT10 N2600 2GB E1 Cedarview-M Intel® Atom™ N2600 2GB - 2 - -
34005-1000-16-2EXT COMe-mCT10 N2600 1GB E1 Cedarview-M Intel® Atom™ N2600 1GB - - - -
Industrial temperature grade modules (XT, -40°C to 85°C operating)
Modules for E2 temperature range are available project based only, please contact your local sales or support for further
details.
Part Number Product Name Processor DDR3 Flash UART TPM onboard FAN
34005-MMFF-CC-X COMe-mCT10 All 1/2GB E2 optional optional n/a YES
The COMe-mCT10 is available for industrial temperature range. General capability was tested for following options:
» CPU: all
» Memory down: 1GB or 2GB industrial temperature grade
» Onboard flash: industrial grade MLC or SLC
» Options: 2x UART, FAN Connector
» Not available: TPM option
