COMe-mCT10 / System Resources
5.5
I2C Bus
I2C Address
Used For
Available
Comment
A0h
FRU-EEPROM
No
Module EEPROM
AEh
FRU-EEPROM
No
Baseboard EEPROM
5.6
JILI I2C Bus
I2C Address
Used For
Available
Comment
A0h
LVDS-EEPROM
No
EEPROM for LVDS Data
5.7
System Management (SM) Bus
Address
Device
Comment
12h
SMART_CHARGER
Not to be used with any SM bus deivce except a charger
14h
SMART_SELECTOR
Not to be used with any SM bus deivce except a selector
16h
SMART_BATTERY
Not to be used with any SM bus deivce except a battery
58h
HWMonitor
Do not use under any circumstances
A0h
DDR3 channel A
Do not use under any circumstances
A2h
DDR3 channel B
Do not use under any circumstances
D2h
Clock Generator
Do not use under any circumstances
47
