COMe-mTT10 / Pinout List
B65
PCIE_RX1-
PCIe lane #1 Receive-
DP-I
PD ~50R(PU @ reset) in TNC
-
B66
WAKE0#
PCI Express Wake Event
I-3.3
PU 1k 3.3V_S5
-
B67
WAKE1#
General Purpose Wake Event
I-3.3
PU 1k 3.3V_S5
-
B68
PCIE_RX0+
PCIe lane #0 Receive+
DP-I
PD ~50R(PU @ reset) in TNC
-
B69
PCIE_RX0-
PCIe lane #0 Receive-
DP-I
PD ~50R(PU @ reset) in TNC
-
B70
GND_23
Power Ground
PWR
-
-
B71
DDI0_PAIR0+
SDVOB_RED_P
DP-O
-
SDVO
B72
DDI0_PAIR0-
SDVOB_RED_N
DP-O
-
SDVO
B73
DDI0_PAIR1+
SDVOB_GREEN_P
DP-O
-
SDVO
B74
DDI0_PAIR1-
SDVOB_GREEN_N
DP-O
-
SDVO
B75
DDI0_PAIR2+
SDVOB_BLUE_P
DP-O
-
SDVO
B76
DDI0_PAIR2-
SDVOB_BLUE_N
DP-O
-
SDVO
B77
DDI0_PAIR4+
SDVOB_INT_P
DP-I
-
SDVO
B78
DDI0_PAIR4-
SDVOB_INT_N
DP-I
-
SDVO
B79
LVDS_BKLT_EN
Backlight Enable
O-3.3
buffered; forced LOW in S5/S3 -
B80
GND_24
Power Ground
PWR
-
-
B81
DDI0_PAIR3+
SDVOB_CLKIN_P
DP-O
100-200MHz
SDVO
B82
DDI0_PAIR3-
SDVOB_CLKIN_N
DP-O
100-200MHz
SDVO
B83
LVDS_BKLT_CTRL
Backlight Brightness Control
O-3.3
-
-
B84
VCC_5V_SBY
+5V Standby
PWR
-
-
B85
VCC_5V_SBY
+5V Standby
PWR
-
-
B86
VCC_5V_SBY
+5V Standby
PWR
-
-
B87
VCC_5V_SBY
+5V Standby
PWR
-
-
B88
BIOS_DIS1#
Disable Module BIOS.Enable boot from SPI on Baseboard I-3.3
PU ~15k in CPLD 3.3V_S5
For ext.SPI
B89
DDI0_HPD
Not Connected
nc
-
not supported
B90
GND_25
Power Ground
PWR
-
-
B91
DDI0_PAIR5+
SDVOB_TVCLKIN_P
DP-I
100-200MHz
SDVO
B92
DDI0_PAIR5-
SDVOB_TVCLKIN_N
DP-I
100-200MHz
SDVO
B93
DDI0_PAIR6+
SDVO_STALLP
DP-I
-
SDVO
B94
DDI0_PAIR6-
SDVO_STALLN
DP-I
-
SDVO
B95
DDI0_DDC_AUX_SEL nc / SDVOB_CTRLCLK (Optional)
nc
optional use by COMe Type1
-
B96
RSVD
nc / SDVOB_CTRLDATA(Optional)
nc
optional use by COMe Type1
-
B97
SPI_CS#
SPI Chipselect
O
3.3V_S5
-
B98
DDI0_AUX+
SDVOB_CTRLCLK
O
-
-
B99
DDI0_AUX-
SDVOB_CTRLDATA
I/O
-
-
B100 GND_26
Power Ground
PWR
-
-
B101 FAN_PWMOUT
Not connected
nc
-
not supported
B102 FAN_TACHIN
Not connected
nc
-
not supported
B103 SLEEP#
Not Connected
nc
-
-
B104 VCC_12V_16
12V VCC
PWR
-
-
B105 VCC_12V_17
12V VCC
PWR
-
-
B106 VCC_12V_18
12V VCC
PWR
-
-
B107 VCC_12V_19
12V VCC
PWR
-
-
B108 VCC_12V_20
12V VCC
PWR
-
-
B109 VCC_12V_21
12V VCC
PWR
-
-
B110 GND_27
Power Ground
PWR
-
-
The termination resistors in this table are already mounted on the module. Refer to the
design guide for information about additional termination resistors.
