COM Express® Eval Carrier Type 2
33
9 LED Indicators
For user convenience, Kontron has included some LED indicators along the side of the board design. These are
noted in the chart below and circled in the picture of the carrier board included at the end of this section.
LED Function
D29 Hdd Activity
D30 Module Rev 2
D31 Module Type 1
D32 Module Type 2
D33 Module Type 3
D34 Module Type 4
D35 Module Type 5
D36 Module Type 6
D37 Module Type 10
D38 Watchdog
D39 THRMTRIP#
D40 SUS_S5#
D42 SUS_S4#
D43 SUS_S3#
D44 SUS_STAT#
D45 V3.3_S5
D46 V5.0_S5
D47 V1.5_S0
D48 V3.3_S0
D49 V5.0_S0
D50 V12_AUX_S0
D51 V12_S0
D54 V-12_S0
