2 com express® connector – Kontron COMe Eval Carrier T2 User Manual
Page 19
COM Express® Eval Carrier Type 2
18
5.2 COM Express® connector
The COM Express® Eval Type 6 is an evaluation carrier board for Type 6 based Computer-on-Modules. The type 6
module pin-out is based on two connectors with 2 rows (Row A and B and Row C and D) with 440 pins overall
(220 pins for each of the two connectors). Please refer to your module documentation for detailed pin-out
descriptions.
