COM Express® Eval Carrier Type 2
12
4.3 Component overview
Connector Short Description
BT1 RTC Battery Socket
D29 HDD Activity LED
D30, D31, D32, D33, D34, D35, D36, D37 Module Type LEDs
D61, D62, D63, D64 POST Code Port 0x81 and Port 0x80
J1 VGA
J4, J5 2x Dual USB 3.0
J6A Gigabit Ethernet
J6B Dual USB 2.0
J7 5x Audio Jack + SPDIF
J11, J65 Internal Audio (CD in, Side)
J14 SMBus Header
J16 S\PDIF Header
J17 I2C Header
J18, J19, J26, J29 SATA Ports
J20 LPC Slot
J22 PCIe x1
J23 PCIe x4
J25 PCIe Graphics
J27, J28 BIOS Disable Jumpers
J31A COM Express AB Connector
J31B COM Express CD Connector
J32 SPI Flash Dediprog Connector
J36 LVDS
J39, J43 2x Fan Header
J38 Fan Power
J46 MicroSD Card
J47 Express Card
J49 PCIe Mini Card
J50 Feature Connector (MARS Compatible)
J54 ATC Connector (4-pin)
J55 ATX Connector (24-pin)
J56 GPIO Connector
J71 CompactFlash
J72 IDE
J73, J74 PCI 32 bit 3.3V /5V Card Slots A & B
J75 COM1
J76 COM2
J77 Parallel port
J79 Keyboard / Mouse
J80 SIO GPIO Header
