COMe Reference Carrier Type 6 / Specification
4
3 Specification
3.1 Functional Specification
» COM Express® COM.0 Rev 2.0 baseboard compatible to Type 6 pin-out based modules
» ATX supply / single supply use
» DVI/CRT on DVI-I
» Display Port (++) connector
» HDMI connector
» LVDS
» HD audio available on frontpanel, rear panel, S/PDIF
» Legacy free (no Super I/O)
» PCIe x4 slot (lanes 1-4)
» Express Card (lane 5)
» mPCIe slot (lane 6)
» SPI flash socket
» feature connector (I2C, SMB)
» POST Code (Port 80h/81h)
» Gigabit Ethernet
» 3 SATA
» eSATA on rear panel
» GPIO pin header
» 6 USB ports (2x USB 3.0)
» SIM Card slot for mPCIe
» Serial port connections for module COMs according to COM Express® spec
» LID#/SLEEP# pin header
» 4 pin FAN header
» SMART Battery support for 2 independent batteries
