5.1.2 Power- and Resetbutton
The COM Express® Reference Carrier Type 6 provides an onboard Reset Button (SW1) and Power Button (SW2). To
connect a front panel button from your chassis use J40 (Power) or J42 (Reset).
Connector
Function
J61
Reset Button
SW1
J62
Power Button
SW2
