COMe Reference Carrier Type 6 / Connector Layout
13
J72 Jumper for disabling optical HD Audio SPDIF
J80 SPI flash Connector
J82 Jumper for BIOS _DIS1#
J83 Ethernet / dual USB connector
J85 Jumper for ATX / single supply mode
J86 Jumper for Wireless Disable at mini PCI Express
J88 COM Express® Connector Row A and B
J89 LID# / SLEEP# Connector
J90 Express Card Connector
J93 SIM Card socket
J100 Jumpter for Power Rail selection for USB4 and 5
J102 Serial COM2 Connector
J103 GPIO Connector
J104 PCIe mini latch for full size cards
J105 PCIe mini latch for half size cards
J106 PCIe x4 connector
J109 Serial COM1 Connector
J110 SMART Battery 2 Connector
J111 SMART Battery 1 Connector
J114 USB Connector for USB port 6 and 7
J115 Display Port Connector
J116 USB Connector (combined with eSATA) for USB port 4 and 5
J117 DVI-I Connector
J118 HDMI Connector
J119 Connector for external Power LED
J120 Pinheader to access LVDS backlight control (PWM)
SW1 Reset Button
SW2 Power Button
U105 CPLD for Power Control
U157 HD Audio Codec
U161 HDMI Level Shifter
U361 LTC1760 Smart Battery Manager
U364 HDMI Level Shifter
