COMe-bIP2 / Features and Interfaces
D95 PEG_TX[13]- B71 HSOn(13) - - - - - -
D98 PEG_TX[14]+ B74 HSOp(14) - - - - - -
D99 PEG_TX[14]- B75 HSOn(14) - - - - - -
D101 PEG_TX[15]+ B78 HSOp(15) - - - - - -
D102 PEG_TX[15]- B79 HSOn(15) - - - - - -
C52 PEG_RX[0]+ A16 HSIp(0) SDVO_TVCLKIN_
P Digital Video TVOUT
sync - - - -
C53 PEG_RX[0]- A17 HSIn(0) SDVO_TVCLKIN_
N
clock input differential - - - -
C55 PEG_RX[1]+ A21 HSIp(1) SDVO_INT_P Digital Video B
interrupt - - - -
C56 PEG_RX[1]- A22 HSIn(1) SDVO_INT_N differential pair - - - -
C58 PEG_RX[2]+ A25 HSIp(2) SDVO_STALL_P Digital Video Field Stall - - DPB_AUX_P DisplayPort B Aux
output
C59 PEG_RX[2]- A26 HSIn(2) SDVO_STALL_N differential pair - - DPB_AUX_N differential pair
C61 PEG_RX[3]+ A29 HSIp(3) - - TMDS_B_HPD# - DPB_HPD# DisplayPort B
Hotplug detect
C62 PEG_RX[3]- A30 HSIn(3) - - - - - -
C65 PEG_RX[4]+ A35 HSIp(4) - - - - - -
C66 PEG_RX[4]- A36 HSIn(4) - - - - - -
C65 PEG_RX[5]+ A39 HSIp(5) - - - - - -
C66 PEG_RX[5]- A40 HSIn(5) - - - - - -
C71 PEG_RX[6]+ A43 HSIp(6) - - - - DPC_AUX_P DisplayPort C Aux
input
C72 PEG_RX[6]- A44 HSIn(6) - - - - DPC_AUX_N differential pair
C74 PEG_RX[7]+ A47 HSIp(7) - - TMDS_C_HPD# - DPC_HPD# DisplayPort C
Hotplug detect
C74 PEG_RX[7]- A48 HSIn(7) - - - - - -
C78 PEG_RX[8]+ A52 HSIp(8) - - - - - -
C79 PEG_RX[8]- A53 HSIn(8) - - - - - -
C81 PEG_RX[9]+ A56 HSIp(9) - - - - - -
C82 PEG_RX[9]- A57 HSIn(9) - - - - - -
C85 PEG_RX[10]+ A60 HSIp(10) - - - - DPD_AUX_P DisplayPort D Aux
input
C86 PEG_RX[10]- A61 HSIn(10) - - - - DPD_AUX_N differential pair
C88 PEG_RX[11]+ A64 HSIp(11) - - TMDS_D_HPD# - DPD_HPD# DisplayPort D
Hotplug detect
C89 PEG_RX[11]- A65 HSIn(11) - - - - - -
C91 PEG_RX[12]+ A68 HSIp(12) - - - - - -
C92 PEG_RX[12]- A69 HSIn(12) - - - - - -
C94 PEG_RX[13]+ A72 HSIp(13) - - - - - -
C95 PEG_RX[13]- A73 HSIn(13) - - - - - -
C98 PEG_RX[14]+ A76 HSIp(14) - - - - - -
C99 PEG_RX[14]- A77 HSIn(14) - - - - - -
C101 PEG_RX[15]+ A80 HSIp(15) - - - - - -
C102 PEG_RX[15]- A81 HSIn(15) - - - - - -
D73 SDVO_CLK B17 PRSNT2# SDVO_CTRL_CLK SDVO I2C clock line DDPB_CTRLCLK HDMI port B Control
Clock
- -
C73 SDVO_DATA B31 PRSNT2#1 SDVO_CTRL_DAT
A
SDVO I2C data line DDPB_CTRLDATA HDMI port B Control
Data DDPB_CTRLDATA only used as boot
strap
D63 RSVD - - - - DDPC_CTRLCLK HDMI port C Control
Clock
- -
D64 RSVD - - - - DDPC_CTRLDATA HDMI port C Control
Data DDPC_CTRLDATA only used as boot
strap
C97 RSVD - - - - DDPD_CTRLCLK HDMI port D Control
Clock
- -
D83 RSVD - - - - DDPD_CTRLDATA HDMI port D Control
Data DDPD_CTRLDATA only used as boot
strap
