COMe-bIP2 / Product Specification
Storage
onboard SSD -
SD Card support -
IDE Interface JMB368 PCIe2PATA
Serial-ATA 2x SATA 6Gb/s, 2x SATA 3Gb/s
SATA AHCI NCQ, HotPlug, Staggered Spinup, eSATA, PortMultiplier
SATA RAID 0, 1, 5, 10, MATRIX (QM77 only)
If SATA AHCI or RAID is disabled in setup, the SATA Interface only supports 3Gb/s transfer
rate and Staggered Spin-Up. To configure a RAID enable RAID support in BIOS Chipset/SATA
settings, connect at least two hard drives and enter the RAID Option ROM by pressing
'CTRL'+'I'
Connectivity
USB 2.0 8x USB 2.0
USB 3.0 -
USB Client -
PCI PEX8112 PCIe2PCI
PCI External Masters 4
PCI Express 5x PCIe x1 Gen2
Max PCI Express 6x PCIe without PCIe2PATA Bridge
PCI Express x2/x4 configuration YES (Softstrap option)
Ethernet 10/100/1000 Mbit
Ethernet controller Intel® 82579LM (Lewisville)
Due to internal chipset configuration the Panther Point only supports up to 4 USB Hubs
PCI Express Configuration
The COMe-bIP2 only supports x1 PCIexpress lane configuration by default. Following x2/x4 configurations are possible via
Management Engine Softstrap Options:
PCIe Port #0 Port #1 Port #2 Port #3 Port #4 Port #5* Port #6* Port #7*
Configuration0 x1 x1 x1 x1 x1 x1 x1 x1
Configuration1 x2 x1 x1 x1 x1 x1 x1
Configuration2 x2 x2 x1 x1 x1 x1
Configuration3 x2 x2 x2 x1 x1
Configuration4 x2 x2 x2 x2
Configuration5 x4 x1 x1 x1 x1
Configuration6 x4 x2 x1 x1
Configuration7 x4 x2 x2
Configuration8 x4 x4
- *PCIe Ports #5 to #7 are only available without PCIe2PATA Bridge, PCIe2PCI Bridge and
without Ethernet Controller
- Configuration0 (default) and Configuration5 (modified FlashDescriptor) are provided in
BIOS download package available on EMD Customer Section
