COMe-bIP2 / BIOS Operation
SystemAgent PCIe Configuration
Feature Options Description
PEG0 - Gen X Gen1
Gen2 Configure PEG0 B0:D1:F0
PEG ASPM Disabled
Auto
ASPM L0s
ASPM L1
ASPM L0sL1
Control ASPM support for the PEG Device. This has no
effect if PEG is not the currently active device
ASPM L0s Root Port Only
Endpoint Port Only
Both Root and Endpoint Ports
Enable PCIe ASPM L0s
PEG state HW Select
Disabled
Enabled
Enable or disable the PEG slot. Option 'HW Select'
controls PEG via PEG_ENABLE# signla
Detect Non-Compliance Device Disabled
Enabled
Detect Non-Compliance PCI Express Device in PEG
De-emphasis Control -6 dB
-3.5 dB Configure the De-emphasis control on PEG
PEG Link Disabled Enabled
Disabled Enable or disable PCIe link disable mechanism for
additional power saving
