COMe-bIP6 / Pinout List

C65

PEG_RX4+

PCIexpress Graphics receive + (4)

DP-I

-

-

C66

PEG_RX4-

PCIexpress Graphics receive - (4)

DP-I

-

-

C67

RSVD

n.c.

nc

-

-

C68

PEG_RX5+

PCIexpress Graphics receive + (5)

DP-I

-

-

C69

PEG_RX5-

PCIexpress Graphics receive - (5)

DP-I

-

-

C70

GND

Power Ground

PWR

-

-

C71

PEG_RX6+

PCIexpress Graphics receive + (6)

DP-I

-

-

C72

PEG_RX6-

PCIexpress Graphics receive - (6)

DP-I

-

-

C73

GND

Power Ground

PWR

-

-

C74

PEG_RX7+

PCIexpress Graphics receive + (7)

DP-I

-

-

C75

PEG_RX7-

PCIexpress Graphics receive - (7)

DP-I

-

-

C76

GND

Power Ground

PWR

-

-

C77

RSVD

n.c.

nc

-

-

C78

PEG_RX8+

PCIexpress Graphics receive + (8)

DP-I

-

-

C79

PEG_RX8-

PCIexpress Graphics receive - (8)

DP-I

-

-

C80

GND

Power Ground

PWR

-

-

C81

PEG_RX9+

PCIexpress Graphics receive + (9)

DP-I

-

-

C82

PEG_RX9-

PCIexpress Graphics receive - (9)

DP-I

-

-

C83

RSVD

n.c.

nc

-

-

C84

GND

Power Ground

PWR

-

-

C85

PEG_RX10+

PCIexpress Graphics receive + (10) DP-I

-

-

C86

PEG_RX10-

PCIexpress Graphics receive - (10) DP-I

-

-

C87

GND

Power Ground

PWR

-

-

C88

PEG_RX11+

PCIexpress Graphics receive + (11) DP-I

-

-

C89

PEG_RX11-

PCIexpress Graphics receive – (11) DP-I

-

-

C90

GND

Power Ground

PWR

-

-

C91

PEG_RX12+

PCIexpress Graphics receive + (12) DP-I

-

-

C92

PEG_RX12-

PCIexpress Graphics receive - (12) DP-I

-

-

C93

GND

Power Ground

PWR

-

-

C94

PEG_RX13+

PCIexpress Graphics receive + (13) DP-I

-

-

C95

PEG_RX13-

PCIexpress Graphics receive - (13) DP-I

-

-

C96

GND

Power Ground

PWR

-

-

C97

RSVD

n.c.

nc

-

-

C98

PEG_RX14+

PCIexpress Graphics receive + (14) DP-I

-

-

C99

PEG_RX14-

PCIexpress Graphics receive - (14) DP-I

-

-

C100 GND

Power Ground

PWR

-

-

C101 PEG_RX15+

PCIexpress Graphics receive + (15) DP-I

-

-

C102 PEG_RX15-

PCIexpress Graphics receive - (15) DP-I

-

-

C103 GND

Power Ground

PWR

-

-

C104 VCC_12V

main input voltage (8.5-20V)

PWR 8.5-20V -

-

C105 VCC_12V

main input voltage (8.5-20V)

PWR 8.5-20V -

-

C106 VCC_12V

main input voltage (8.5-20V)

PWR 8.5-20V -

-

C107 VCC_12V

main input voltage (8.5-20V)

PWR 8.5-20V -

-

C108 VCC_12V

main input voltage (8.5-20V)

PWR 8.5-20V -

-

C109 VCC_12V

main input voltage (8.5-20V)

PWR 8.5-20V -

-

C110 GND

Power Ground

PWR

-

-
