COMe-bIP6 / Product Specification
Connectivity
USB 2.0 8x USB 2.0
USB 3.0 4x USB 3.0
USB Client -
PCI -
PCI External Masters -
PCI Express 7x PCIe x1 Gen2
Max PCI Express 8x PCIe without LAN
PCI Express x2/x4 configuration YES (Softstrap option)
Ethernet 10/100/1000 Mbit
Ethernet controller Intel® 82579LM (Lewisville)
Due to internal chipset configuration the Panther Point only supports up to 4 USB Hubs
PCI Express Configuration
By default, the COMe-bIP6 supports x1 PCIexpress lane configuration only. Following x2/x4 configurations are available
via Management Engine Softstrap Options with a customized BIOS version.
PCIe Port #0 Port #1 Port #2 Port #3 Port #4 Port #5 Port #6 Port #7*
Configuration0 x1 x1 x1 x1 x1 x1 x1 x1
Configuration1 x2 x1 x1 x1 x1 x1 x1
Configuration2 x2 x2 x1 x1 x1 x1
Configuration3 x2 x2 x2 x1 x1
Configuration4 x2 x2 x2 x2
Configuration5 x4 x1 x1 x1 x1
Configuration6 x4 x2 x1 x1
Configuration7 x4 x2 x2
Configuration8 x4 x4
- *PCIe Port #7 is available without Ethernet Controller
- Configuration0 (default) and Configuration5 (modified FlashDescriptor) are provided in
BIOS download package available on EMD Customer Section
Ethernet
The Intel® 82579LM (Lewisville) ethernet supports:
» Jumbo Frames
» MACsec IEEE 802.1 AE
» Time Sync Protocol Indicator
» WOL (Wake On LAN)
» PXE (Preboot eXecution Environment)
