5.1.20 X102 PC/104 BUS Interface
Pin
A:
B:
C:
D:
0
Ground
Ground
1
IOCHCK
Ground
SBHE
MEMCS16
2
SD7
RESET
LA23
IOCS16
3
SD6
+5Volt
LA22
IRQ10
4
SD5
IRQ9
LA21
IRQ11
5
SD4
NC
LA20
IRQ12
6
SD3
DRQ2
LA19
IRQ15
7
SD2
(-12Volt)
LA18
IRQ14
8
SD1
0WS
LA17
DACK0
9
SD0
+12Volt
MEMR
DRQ0
10
IOCHRDY
Ground NC
MEMW
DACK5
11
AEN
SMEMW
SD8
DRQ5
12
SA19
SMEMR
SD9
DACK6
13
SA18
SIOW
SD10
DRQ6
14
SA17
SIOR
SD11
DACK7
15
SA16
DACK3
SD12
DRQ7
16
SA15
DRQ3
SD13
+5Volt
17
SA14
DACK1
SD14
MASTER
18
SA13
DRQ1
SD15
Ground
19
SA12
REF
Ground
Ground
20
SA11
SYSCLK
21
SA10
IRQ7
22
SA9
IRQ6
23
SA8
IRQ5
24
SA7
IRQ4
25
SA6
IRQ3
26
SA5
DACK2
27
SA4
TC
28
SA3
ALE
29
SA2
+5Volt
30
SA1
OSC
31
SA0
Ground
32
Ground
Ground
5.1.21 X110 LPC-Port
Note:
Only for factory and POD-Diagnostic use.
For more information please see the Section on BIOS Diagnostics – Post Codes in the BIOS/Driver/Software manual
"Geode LX800 / LX900" found on the Product CD or in the download area of Kontron Compact Computers' website.
Pin
Signal
Pin
Signal
1
VCC 3.3V
2
LAD0
3
LFrame#
4
LAD1
5
PCI_RST#
6
LAD2
7
FWH_TBL#
8
LAD3
9
VCC 5V
10
PCI_RST#
11
LPC_Clock
12
FWH_Control
13
Ground
14
NC
5.1.22 X230 JTAG-Port
Pin
Signal
Pin
Signal
1
TCK
2
TMS
3
TDI
4
TDO
