Page 34: X30 printer port (centronics)
MSM800XEV/XEL
/ Connectors & Jumpers
www.kontron.com
32
5.1.6 X29
Sound/Audio Port
Pin
Signal
Pin
Signal
1
Input_CD_L
2
GND
3
Input_CD_R
4
Input_AUX_L
5
GND
6
Input_AUX_R
7
Input_Line_L
8
GND
9
Input_Line_R
10
GND
11
Input_MIC 1
12
GND
13
Input_MIC 2
14
Input Mono
15
Output Front / Line Left
16
GND
17
Output Front / Line Right
18
GND
19
Output Surround Left
20
GND
21
Output Surround Right
22
GND
23
Output_Center
24
GND
25
Output_Subwoofer
26
GND
27
SPDIF Digital Output
28
Jack Sense 0 Input
29
Jack Sense 2 Input
30
Jack Sense 3 Input
The audio/sound feature is only available on the XEV board, not on the XEL.
5.1.7 X30
Printer Port (Centronics)
The printer connector provides an interface for 8bit Centronics printers.
Header onboard
D-SUB connector
Signal
Pin 1
Pin 1
Strobe
Pin 3
Pin 2
Data 0
Pin 5
Pin 3
Data 1
Pin 7
Pin 4
Data 2
Pin 9
Pin 5
Data 3
Pin 11
Pin 6
Data 4
Pin 13
Pin 7
Data 5
Pin 15
Pin 8
Data 6
Pin 17
Pin 9
Data 7
Pin 19
Pin 10
Acknowledge
Pin 21
Pin 11
Busy
Pin 23
Pin 12
Paper end
Pin 25
Pin 13
Select
Pin 2
Pin 14
Autofeed
Pin 4
Pin 15
Error
Pin 6
Pin 16
Init printer
Pin 8
Pin 17
Shift in (SI)
Pins 10, 12, 14, 16, 18, 26
Pin 18-22
Left open
Pins 20, 22, 24
Pin 23-25
GND
