KTD-S0005-C Page 10 Getting Started
MOPSlcdLX User's Guide
4 Getting Started
Getting started with the MOPSlcdLX is very easy. Take the following steps:
❶ Plug a suitable DDR-SDRAM memory module into the RAM socket.
❷ Plug the MOPSlcdLX to the PC/104 bus connector on the starter kit baseboard.
❸ Make all necessary connections from the MOPSlcdLX to the starter kit board (cables come with
the starter kit). The starter kit board offers various interfaces on standard connectors.
❹ Connect the CRT monitor to the CRT interface or a LCD panel to the JILI interface by using the
corresponding adapter cable.
❺ Plug a keyboard and/or mouse to the PS/2 connectors.
❻ Plug a data cable to the hard disk interface. Attach the hard disk to the connector at the oppo-
site end of the cable. If necessary connect the power supply to the hard disk’s power connec-
tor.
❼ Make sure all your connections have been made correctly. Turn on the power.
❽ Enter the BIOS by pressing the Del key during boot-up. Make all changes in the BIOS Setup.
See the BIOS Setup chapter of this manual for details.
