Introduction
AM5020
Page 1 - 12
ID 1043-6198, Rev. 1.0
P R E L I M I N A R Y
LEDs
Module Management
LEDs
•
LED1 (red):
Out-of-Service LED
•
LED2 (red/green):
Health LED
•
HS LED (blue):
The hot swap indicator provides basic feed-
back to the user on the hot swap state of the
module. The HS LED states are off, short
blink, long blink, and on.
User-Specific LEDs
•
ULED3 (red/green):
AMC Ethernet port A link signal status,
AMC port 0 (green) + POST code
•
ULED2 (red/green):
AMC Ethernet port B link signal status,
AMC port 1 (green) + POST code
•
ULED1 (red/green):
SATA channels active (green) + POST code
•
ULED0 (red/green):
POST code
Ethernet LEDs
•
Act (green):
Network / Link Activity
•
Speed (green/yellow):
Network speed
Ti
m
er
Watchdog Timer
•
Software-configurable, two-stage Watchdog with programmable timeout
ranging from 125 ms to 4096 s in 16 steps
•
Serves for generating IRQ or hardware reset
System Timer
•
The Intel® QM57 chipset contains three 8254-style counters which have
fixed uses
•
In addition to the three 8254-style counters, the Intel® QM57 chipset in-
cludes eight individual high-precision event timers that may be used by
the operating system. They are implemented as a single counter each
with its own comparator and value register.
IPMI
Module Management
Controller
•
NXP® LPC2368 ARM7 microcontroller with redundant 512 kB firmware
flash and automatic roll-back strategy
•
The MMC carries out IPMI commands such as monitoring several on-
board temperature conditions, board voltages and the power supply sta-
tus, and managing hot swap operations.
•
The MMC is accessible via a Local Intelligent Platform Management Bus
(IPMB-L) and one host Keyboard Controller Style interface (KCS).
Hot Swap
The AM5020 has full hot swap capability.
Thermal Management
CPU and board overtemperature protection is provided by:
•
Temperature sensors integrated in Intel® Core™ i7 processor:
•
Two temperature sensors for monitoring the processor cores
•
One temperature sensor for monitoring the graphics controller and
the memory controller
•
One temperature sensor integrated in the Intel® QM57 chipset for mon-
itoring the chipset
•
One onboard air temperature sensor for monitoring the board tempera-
ture
•
Specially designed heat sinks
Secu
rity
TPM
Trusted Platform Module (TPM) 1.2 for enhanced hardware- and software-
based data and system security (on request)
Table 1-2:
AM5020 Main Specifications (Continued)
AM5020
SPECIFICATIONS
