AM5020
Introduction
ID 1043-6198, Rev. 1.0
Page 1 - 11
P R E L I M I N A R Y
Integ
rated
Controller
Graphics controller
High-performance 3D graphics controller integrated in the processor:
•
Supports resolutions up to 1920 x 1200 pixels @ 60 Hz using HDMI
and DVI
•
Dynamic Video Memory Technology
Onboard
Controller
Gigabit Ethernet
Intel® 82580EB Quad Gigabit Ethernet PCI Express bus controller with
advanced management features such as serial redirection over LAN:
•
Two interfaces routed to the front I/O connectors
•
Two interfaces routed to the AMC Card-edge connector
Serial
One 16550-compatible UART routed either to the front I/O (RS-232 signaling)
or the AMC Card-edge connector (TTL level)
A
M
C Interconne
ction
Gigabit Ethernet
Common Options Region ports 0-1:
•
Two Gigabit Ethernet SerDes ports
Serial ATA
Common Options Region ports 2-3:
•
Two Serial ATA ports
Extended Options Region ports 12-13:
•
Two Serial ATA ports
PCI Express
Fat Pipes Region ports 4-11:
•
Two x4 or eight x1 PCI Express 2.0 interfaces operating at 2.5 GT/s as a
root complex controller only
Debug Interface
Extended Options Region port 14:
•
One debug port
Serial Interface
Extended Options Region port 15:
•
One serial port
Clock
Clock:
•
Bidirectional PCI Express reference clock (FCLKA)
Connectors
Front Panel
Connectors
•
Two USB 2.0 ports on two 4-pin, USB Type A connectors, J6 and J7
•
Two Gigabit Ethernet ports on two RJ-45 connectors, J1 and J3
•
One serial port (COMA) with RS-232 signal level on an RJ-45 connector,
J4
•
One DVI-D connector with digital signals only, J9
Onboard Connectors
•
Serial ATA extension connector, J5, for the SATA Flash module
•
Serial ATA connector, J8, for connecting an onboard SATA 2.5” HDD/
SSD
AMC Card-edge
Connector
•
One 170-pin AMC Card-edge connector
Switches
DIP Switches
Two DIP switches for board configuration, SW3 and SW4, consisting of four
switches each
Reset Switch
One front panel hardware reset switch, SW2
Table 1-2:
AM5020 Main Specifications (Continued)
AM5020
SPECIFICATIONS
