Functional Description
Page 24 AM4311 User Guide
2.5.2.2 OEM Set Control State
Each SFP can separately be switched to one of the mentioned AMC ports.
Example 1: Configure SFP1 (Control ID 0) to port 11 (Control State 1)
ipmitool –t 0x7a –b 7 raw 0x3e 0x20 0x0 0x1
Example 2: Configure SFP2 (Control ID 1) to port 1 (Control State 0)
ipmitool –t 0x7a –b 7 raw 0x3e 0x20 0x1 0x0
Command Name NetFn LUN Command Number
CmdSetControlState 3Eh 0 - BMC 20h
Byte Num Data Field
Request Data 1 Control ID
0 – SFP#1
1 – SFP#2
2 – SFP#3
3 – SFP#4
2 Control State
Control Number 0: SFP#1
0 – AMC port 0
1 – AMC port 11
Control Number 1: SFP#2
0 – AMC port 1
1 – AMC port 10
Control Number 2: SFP#3
0 – AMC port 20
1 – AMC port 9
Control Number 3: SFP#4
0 – AMC port 4
1 – AMC port 8
Control Number 4: Loopback
0..7 – Loopback Mode
Bit [2] – AD8159 LB_C Pin 65 state
Bit [1] – AD8159 LB_B Pin 66 state
Bit [0] – AD8159 LB_A Pin 67 state
Default value is 00h (loopback mode disabled).
Response Data 1 Completion Code
