Functional Description
Page 11 AM4311 User Guide
4 3 B1:Module-
HotSwap F2h (Module Hot Swap) 6Fh (Sensor Specific)
Offset 0: Module Handle Closed
Offset 1: Module Handle Opened
Offset 2: Quiesced
Offset 3: Backend Power Failure
Offset 4: Backend Power Shutdown
Refer to AMC.0 R2.0 Section 3.6.6 Module Hot
Swap Sensor.
5 4 B1:IPMBL State C3h (OEM Kontron) 6Fh (Sensor Specific)
Offset 0: IPMB-A disabled, IPMB-B disabled
Offset 1: IPMB-A enabled, IPMB-B disabled
Offset 2: IPMB-A disabled, IPMB-B enabled
Offset 3: IPMB-A enabled, IPMB-B enabled
6 5 B1:Temp-Center 01h (Temperature) 01h (Threshold Based)
7 6 B1:Temp-Outlet 01h (Temperature) 01h (Threshold Based)
Sensor is only readable when Payload Power is on.
8 7 B1:Temp-Inlet 01h (Temperature) 01h (Threshold Based)
Sensor is only readable when Payload Power is on.
9 8 B1:Vcc 3.3V 02h (Voltage) 01h (Threshold Based)
Sensor is only readable when Payload Power is on.
10 9 B1:Vcc 3.3V SUS 02h (Voltage) 01h (Threshold Based)
11 10 B1:Vcc 12V 02h (Voltage) 01h (Threshold Based)
Sensor is only readable when Payload Power is on.
12 11 B1:Pres SFP-1 25h (Entity Present) 6Fh (Sensor specific)
Offset 0: Entity Present
Offset 1: Entity Absent
Offset 2: Entity Disabled
Sensor is only readable when Payload Power is on.
13 12 B1:Pres SFP-2 25h (Entity Present) 6Fh (Sensor specific)
Offset 0: Entity Present
Offset 1: Entity Absent
Offset 2: Entity Disabled
Sensor is only readable when Payload Power is on.
14 13 B1:Pres SFP-3 25h (Entity Present) 6Fh (Sensor specific)
Offset 0: Entity Present
Offset 1: Entity Absent
Offset 2: Entity Disabled
Sensor is only readable when Payload Power is on.
Table 2-3: Sensor List AM4311 (Continued)
ID Num ID string Sensor Type Code Event Type Code / Event Offsets
